Brand: Radian Qbio
Model: Heart Guardian HR-701 Plus AED Machine With Monitor
Part Number: HR-701 Plus
Your instant response partner when cardiac emergencies strike.
The Heart Guardian HR-701 Plus AED from Radian Qbio is an intuitive, semi-automatic defibrillator featuring a 4.3″ color LCD screen with real-time ECG display and video-voice guidance for CPR and defibrillation. Designed for both public and professional use, it features simple adult/child mode switching, reliable high-energy shocks, and uses a long-life LiMnO₂ (12 V) battery with up to 4 years of standby, and automatic self-testing to ensure it’s always ready for emergencies.
Explore related life-saving devices, including the HR-501T Trainer and HR-501 AED with Monitor.
Radian Qbio Heart Guardian HR-701 Plus AED Machine With Monitor
The HR-701 Plus is an advanced AED equipped with a built-in LCD monitor that provides clear visual guidance during emergencies. Its fast heart-rhythm analysis and automatic shock delivery make it easy for anyone to use. Designed for rapid response, it ensures reliable performance when every second counts.
Built with durable construction and continuous self-testing, the HR-701 Plus stays ready 24/7 in any environment. The visual monitor enhances clarity, supporting both trained responders and bystanders. Perfect for workplaces, public areas, schools, hotels, and healthcare facilities needing a high-performance AED solution.
What is Included:
Heart Guardian HR-701 Plus AED Machine With Monitor
- Heart Guardian HR-701 Plus AED Adult/Paediatric Electrode Pad P-701
- Heart Guardian HR-701 Plus Non Rechargeable Replacement Lithium Manganese Dioxide Battery BT-701 (4 -Year Warranty)
- Storage and protection Semi-Rigid AED Case HR-B7
- Holding strip for the HR-B7 AED Bag
- AED manual
- 8 years warranty
- AED Stickers
Key Features of HR-701 Plus AED Machine With Monitor
Advanced LCD monitor provides real-time visual rescue guidance.
Automatic heart rhythm analysis for fast and accurate shock decisions.
Fully automatic operation for stress-free use during emergencies.
Clear voice prompts support users through every step of the rescue.
High-visibility display enhances clarity in noisy or crowded environments.
Pre-connected adult pads enable immediate deployment.
Durable, impact-resistant design for reliable use in public locations.
Long-lasting lithium battery ensures consistent power and readiness.
Continuous self-tests (daily/weekly/monthly) maintain device reliability.
Bright status indicator shows operational condition at a glance.
Lightweight and compact for easy installation anywhere.
Data storage capability allows event recording for post-incident review.
Visual and audible alerts enhance user safety and awareness.
Minimal maintenance requirements reduce overall operating costs.
Designed for rapid, effective response to sudden cardiac arrest.
Specifications of HR-701 Plus AED
Origin | KOREA |
Model | HR-701 Plus |
Defibrillator Type | Semi-Automated External Defibrillator (SAED) |
Waveform | Biphasic Truncated Exponential (BTE) |
Energy Levels | Adult: 150J / 200J / 250J Child: 50J |
Energy Delivery | High-Capacitor Charging |
Impedance Range | 25 Ω – 175 Ω |
Patient Analysis Time | ECG Analysis in approximately 8.5 seconds |
Monitor Display | 4.3-inch High-Resolution Color LCD |
Display Features | Real-time ECG Waveform and Video Prompts for operation and CPR guidance |
User Interface | Voice prompts, Video prompts, Status Indicators (LED/LCD) |
Controls | Power Button, Shock Button, Adult/Child Mode Switch, Language Select Button |
CPR Coaching | Voice coaching with beep sound for compression rate/timing |
Electrode Pads | P-701: Non-polarized, common use for Adult and Child (Single type for all ages) |
Pads Shelf Life | 2 years (from date of manufacture/shipment) |
Battery Type | LiMnO2 (Lithium Manganese Dioxide) Non-Rechargeable (BT-701) |
Battery Specs | 12 V DC, 6.4 A |
Battery Capacity | At least 28 discharges at maximum energy (or 10 hours of continuous monitoring) |
Battery Shelf Life | 4 years (in standby mode) |
Data Storage | 10 Mbyte (approx. 100 ECG data and logs) |
Data Transfer | Bluetooth, SD-Card, USB Port |
Self-Tests | Automatic (Daily, Weekly, Monthly checks on battery, pads, SD card, charge/discharge) |
Dimensions (W x L x H) | 222 mm (W) × 280 mm (L) × 74.4 mm (T) |
Weight (with battery) | 2.3 kg |
Ingress Protection (IP) | IP55 (Dust protected and protected against low-pressure water jets from any direction) |
Hamid Safety is Radian Qbio Heart Guardian HR-701 Plus AED Machine With Monitor supplier in Dubai UAE, Saudi Arabia KSA and Oman offering best prices! We deliver all orders to door within UAE and internationally with custom duty and taxes paid
We have served customers from Dubai, Abu Dhabi (UAE), Saudi Arabia (KSA), Bahrain, Iraq, Kuwait, Oman, Qatar, Angola, Algeria, DRC Congo, Egypt, Ghana, Kenya, Nigeria, Tanzania, Azerbaijan, Kazakhstan, Turkmenistan & Russia
Radian Qbio Heart Guardian HR-701 Plus AED Machine With Monitor Accessories
Replacement AED Pad for Heart Guardian HR-701 Plus AED Machine With Monitor P-701
Part Number: P-701
Adult/Paediatric defibrillation electrode pads are designed exclusively for the Radian Qbio Heart Guardian HR-701
Hamid Safety is supplier/Reseller of Heart Guardian HR-701 AED Adult/Paediatric Electrode Pad P-701 in Dubai UAE, Saudi Arabia KSA, and Oman.
Replacement AED Battery for Heart Guardian HR-701 Plus AED Machine With Monitor BT-701
Part Number: BT-701
Heart Guardian HR-701 Plus AED Non Rechargeable Replacement Lithium Manganese Dioxide Battery (LiMnO₂ 12 V DC, 4.2Ah) Battery comes with 4-year comprehensive warranty.
Hamid Safety is supplier/Reseller of Heart Guardian HR-701 Plus AED Non Rechargeable Replacement Lithium Manganese Dioxide Battery in Dubai UAE, Saudi Arabia KSA, and Oman.
